OS Ankerplaat RVS div. maten
Ankerplaten
• RVS AISI 316
| Artikelnummer | Afmeting mm | W mm | X mm | Y mm | Z mm | D1 mm | D2 mm | L1 mm | L2 mm |
| 2302004 | 3,0 - 4,0 | - | 9,0 | 3,0 | 5,0 | 20,5 | 5,2 | 17,0 | 21,5 |
| 2302005 | 5,0 | - | 10,0 | 3,0 | 5,0 | 20,5 | 5,2 | 17,0 | 21,5 |
| 2302006 | 6,0 | - | 13,5 | 3,0 | 6,5 | 30,6 | 6,8 | 22,0 | 28,0 |
| 2302007 | 7,0 | 23,0 | 15,0 | 4,0 | 10,5 | 39,2 | 6,8 | 20,0 | 37,0 |
| 2302008 | 8,0 | 23,0 | 17,0 | 4,0 | 10,5 | 39,2 | 6,8 | 20,0 | 37,0 |
Klik voor vergroting
